Top Quality OEM Railway Clamp Plate RC2150804 manufacturer from China Kunshan Alex Railway Fastening Co.,Ltd.

Price:	1.2 USD
Payment Terms:	T/T
Place of Origin:	Jiangsu, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: RC2150804

Production Capacity: 1000 Tons/ Month

Delivery Date: 20days

Material:: Steel 35#, 45#, Q235, 65mn

Means of Transport: Ocean,Land,Air

Packing: 25kg Per Woven Bag in Fumig...

Brand Name: Alex

Certification:: AREMA, GB/T 1222, DIN 17221

Trademark:
Alex
Packing:
25kg Per Woven Bag in Fumigation Free Pallet
Standard:
SGS
Origin:
Jiangsu
HS Code:
7307110000

Product Details

Basic Info.

Model NO.:RC2150804

Type:Rivet

Clamp Material:Carbon Steel Q235,or Qt400-15,Qt450-10,Qt500-7

Surface:Plain Oiled, Oxygen Black

Produce Type:Sand Casting, Hot Forging

Supply Ability:5000 PCS Per Day

MOQ:3000 PCS

Payment Term:Tt 30% Deposit and Balance to Be Paided Before

Certification:ISO9001-2008

Sample:Free with Courier Fee by Buyer

Export Markets:Global

Additional Info.

Trademark:ALEX

Packing:Double Woven Bag or Bundled by Wire, Put in Pallet

Standard:KPO 3, KPO6, Customized according to clients′ dwg.

Origin:Suzhou Jiangsu

HS Code:73071100

Production Capacity:3000 PCS Per Day

Product Description

Rail Clamp
Our rail clamp is made from low carbon steel or alloy steel by hot forging, rolling and casting, based on the requirements of our customers. We produce rail clamp in accordance with DIN, GB/TB, AREA standards and customer drawings. We also produce rail clips in accordance with AREA, ranging from 52 lbs rail, 62 lbs rail, 114 lbs rail, 106 lbs rails, 120 lbs rails, 128 lbs rails, 171 lbs rails and 75 lbs rails.
The rail clamp we produced, i.e., S18, S20, S30, S33, KP03, KP06 and KP03.

KPO Clamp Rail Fastening System Technical Parameters

Part name	Type	Material	Finish	Remark
KPO clip	KPO3, KPO6, KPO9	Q235	Plain oiled	Standard: DIN5906
HS bolt	HS26, HS32	Grade4.6: Q235 Grade5.6: 35# Grade8.8: 45#	Plain oiled, black oxide, galvanized, hot dip galvanized	Diameter: 22mm or 24mm. Length: 55mm, 65mm, 75mm, 90mm Standard: UIC864-2
Hex nut	As ordered	Grade 5: 35# Grade 8: 45#	Plain oiled, black oxide, galvanized, hot dip galvanized	Standard: DIN985
Double coil spring washer	As ordered	65Mn	Plain oiled, black oxide, galvanized, hot dip galvanized	Standard: UIC864-3
screw spike	M24×150mm M24 ×160mm M24 ×180mm or other length as ordered	Grade 4.6: Q235 Grade 5.6: 35# Grade 8.8: 45#	Plain oiled, black oxide, galvanized, hot dip galvanized, Dacromet and sherardized.	Standard: ISO898-1, UIC864-1 and NF F500-50
Base plate	UIC54,UIC60, 50kg rail, 60kg rail,S49 in ordered size	Casting iron QT500-7, QT450-10, or forging low carbon steel or high carbon steel	Plain oiled	Standard: UIC864-6

The rail clamp is packed in wooden boxes or sacks and wooden pallets. On average, 25kgs per package.

We are a leading rail clamp manufacturer in China. We can also make other rail fastenings such as rail clip, railway screw spike, plastic dowel, rail pad, railway insulator, rail fish bolt, railway base plate, rail anchor, railway shoulder, rail bolt, flat and spring washer, fastening system of E type/SKL type/KPO type/Nabla type. Thank you for visiting our website. Welcome to choose the rail clamp from Kunshan ALEX Railway Fastening Co., Ltd.
